Mfr: Visaton GmbH & Co. KG
Series: Miniature Speaker
Package: Bulk
Product Status: Active
Technology: -
Type: General Purpose
Frequency Range: 500 Hz ~ 20 kHz
Frequency - Self Resonant: 950Hz
Impedance: 8 Ohms
Efficiency - dBA: 72.00
Efficiency - Testing: 1W/1M
Efficiency - Type: Sound Pressure Level (SPL)
Power - Rated: 1 W
Power - Max: 1.5 W
Port Location: Top
Shape: Oval, Rectangular Frame
Material - Cone: Plastic
Material - Magnet: -
Ingress Protection: -
Termination: Solder Pads
Size / Dimension: 0.984\ L x 0.551\ W (25.00mm x 14.00mm) Height - Seated (Max): 0.209\ (5.30mm)
